How to remove the rising damp with the HS-221 SYSTEM

WHAT IS THE HS-221 SYSTEM?

Witch model correspond to your ground floor?

• The HS-221 must be connected continuously, but its consumption is very low. In a year consumes less electricity than a TV st in a day.
• Can be supplied with an external feeder 12V 2A with 5mm jack with negative on the outside and with round or flat plug for 100VAC up to 240VAC.
• The equipment has a guarantee of good performance of 30 years and satisfaction.
• Normally, in brick walls or concrete blocks walls, removes moisture by capillarity in less than 4 months.
• n cases of old houses with very thick walls, and without foundation, may take to dry as maximum 9 months.
• Only leaves on the walls between 3% and 6% water by weight, because drying more would deteriorate certain construction materials.
• Installation of the equipment is as easy as hanging a picture. You can do it yourself with the instructions that we attach with the equipment.

The HS-221 is installed on a thick wall of the house, preferably those facing the exterior or neighbor.

Transmission by walls and floors of low frequency waves dry all walls and floors of the house.

As previously indicated the emission power of the equipment varies according to the m² of the ground floor or basement and consequently the price.

This equipment must be placed tightly in a wall such as those that give outside or to the neighbor, as this way the waves are transmitted very easily all over the periphery and from there the interior is attacked by partitions, walls and the floor screed.

If we hit a hammer on a peripheral wall of the house the sound can be seen in any room, making the same effect the electromagnetic impulses we transmit, which are certified to be safe for the health of animals and plants. It’s like we have a membrane-free speaker without making sounds.

The HS-221 is installed as a picture on the wall, but it is important to consider the following points.

• The HS-221 should be installed directly on a thick wall without intermediate panels, wood, ceramics, marble.
• It is important that the back is in good contact with the wall without gaps.
• The most suitable place is in a bearing wall that gives to the outside or neighbour.
• Best if placed about 12 inch from the ground and less than 1m from a plug.
• Should be placed in a wall that has moisture or are close.
• If the plant is elongated place it near where there is more moisture, although it will dry all the walls, even if they are in other rooms.

It is safer, more effective, and cheaper to dry the walls with HS-221 before rehabilitating the walls, making sure to follow the steps in the attached video.

• You should first install the HS-221 directly on a thick wall by making good contact with it and following the instructions in the installation video.
• When the wall is dry proceed to sanitise the surface of the wall, removing the saltpeter, and if there is plaster that has been wet it is necessary to remove it repicando the wall up to about 30cm above where the moisture has come.
• If you have had to hammer the wall it is advisable to put a layer of mortar with lime of at least 1cm. If you want to have a finer finish you need to put a layer of mortar to the fine lime.
• Si desea pintar debe hacerlo con pintura al silicato que también es transpirable.

In case you need urgently rehabilitate, you have to follow the instructions of the video to achieve a lasting drying.

• It is advisable to install the HS-221 15 days before starting rehabilitation.
• Pick up the wall if you have a layer of plaster on top of the brick, until at least 30cm from where the moisture has come.
• If the wall has to be grouted, it is advisable to put a layer of mortar to the lime of at least 2cm, which can be finished with a layer of mortar to the fine lime.
• If you want to paint it must be done with silicate paint that is also breathable.

The lime mortar retains moisture for one year, giving HS-221 time to dry moisture by capillarity.

Humitat-Stop system HS-221 far exceeds the electroosmosis systems on the market because:

• By transmitting the HS-221 waves through walls and floors and not through the air it reaches the moisture more easily by drying 4 times faster.
• Range of ranges in m² of HS-221 from 50m² to 2500m² with a single apparatus. With electroosmosis the maximum range is 16m around the equipment.
• Electro-osmosis equipment produces interference in radio, tv, alarms, etc., by transmitting a frequency of 3Mhz through the air.
• The consumption of electro-osmosis systems is in the order of 12W to 15W and consequently they spend much more electricity than the HS-221 that consumes less than 1W.
• By heating more electro-osmosis equipments age their components faster and can only give a guarantee of operation of 7 years.
• The HS-221 has a 30-year warranty because it works without heating.
• We are so sure of the drying results that we also give a drying guarantee to return the money if after a year we are not drying your rising damp.

Certainly the HS-221 system proves, which is the best system to remove rising damp forever.

• Global solution. With a single device removes moisture by capillarity of the entire ground floor or basement.
• Effective system.Dry walls forever in less time and at less cost.
• Installation without works. Just hang it on the wall like a picture.
• Save money. It does not need maintenance with very little consumption. Saves on house maintenance, heating and home appliance repairs.
• System certified by the EC in Europe, FCC in the USA, and by the ICNIRP not to be harmful to the health of persons, animals and plants.
• Is eco-friendly because they use waves like those found in nature, and no resins are injected into the walls that contaminate the aquifers.
• Obtain more information downloading the brochure of the HS-221 where all technical characteristics are also indicated.
• With the direct fixing of the mounting screws to the wall and the two pairs of test screws supplied with the device, the drying can be monitored with the help of a multimeter on the scale of 200kohm and following the procedure explained in the equipment manual

This new model HS-221 PRO+ is CE certified and also complies with the ROHS regulation of not containing hazardous materials for our ecosystem. Although it has the same electronics as the HS-221 model, the geomagnetic system has been added, achieving an efficiency increase of 5% to our electro-physical system.

The great novelty of this system is that a reader has been added to the relative humidity on the wall where it is installed and thanks to a Bluetooth connection, are transmitted with a free downloadable mobile app from APPLE STORE or GOOGLE PLAY, and so you can track the evolution of humidity on the wall thanks to the Bluetooth connection of your mobile Apple or Android.

HOW TO TRACK WALL DRYING WITH HS-PRO+?

There are two ways to download the app:

-By downloading it directly from the App Store or Google Play.

- Using the QR code for Apple iOS or Android phones.

• You must first download the app from Google Play or Apple Store.
• Click on the search symbol (magnifying glass) and write Rising damp, but in Google Play within quotation marks.
• You have to download the application that has as logo a house with a few drops as seen in the following image:
• For this application to work on your mobile you must have Bluetooth enabled and placed near the HS-PRO+.
• When you click on the logo of the application on your mobile the image of a wall appears on the screen, and when you click on connect the mobile communicates with the HS-PRO+ and the relative humidity reading appears.
• Readings appear with a red background if humidity is high, orange when moderate, and green when already correct.
• You must exit the application by clicking on disconnect, and when connecting again you will have a new reading.
• The application on your mobile is recording the readings with the corresponding dates, thus facilitating the monitoring of drying.
• It is advisable to periodically clean the back of the wall in contact with the equipment so as not to accumulate salts that could distort the readings.

If you use the QR code, you must read the corresponding QR code to download the app and proceed as in the previous case.
